Oil Tanker EQ5311GJYT
New product
3 Items
In stock
Warning: Last items in stock!
Data sheet
| Compositions | Non-asbestos: NA |
| Styles | Overhaul package: FS |
| package | Bare packing |
More info
2.For tank welding, we use specific welding machine which can realize single-side welding and double-side molding at one time, welding line is even and smooth, blazonry, strong and not leak.
3.Auxiliary frame is employ international high strength steel, light deadweight, and ensure resistance to twisting forces, shock resistance, bumped against ability, meet different pavement bearing requirements.
|
EQ5311GJYT Oil Tanker. |
|
|
Overall Dimensions(mm) |
11980*2500*3760,3200 |
|
Cargo box Inner Size(mm) |
9100*2285*1985(Effective volume of tank is 27.6m3) |
|
Wheelbase(mm) |
1950+4250+1300,1950+4250+1350,1950+4500+1300 |
|
Gross Weight(kg) |
31000 |
|
Rated Loaded Weight(kg) |
18500,18435 |
|
Curb Weight(kg) |
12370 |
|
Engine Model |
C260 33 |
|
Displacement/Power(ml/kw) |
8300/191 |
|
Displacement standar |
Euro 3 |
|
Oil Consumption(L/100km) |
29.9 |
|
Effective Volume(L) |
27600 |
|
Maximum speed (km/h) |
90 |
|
Cab Type |
High-top Twin -Flat Head Cab |
|
Audio Configuration |
Mp4 |
|
Heating and Cooling System |
Air Conditioning, warm air |
|
Cold Boot Temperature Range |
General condition:-10to55℃；special circumstances：-40to55 |
|
Transmission Gear |
Shanxi Fast nine Gear transmission |
|
Oil tank capacity |
Completed steel 350L |
|
Tire Size |
11.00-20, 11.00R20, 12.00-20, 12.00R20 |
|
Chassis Model |
DFL1311A3 |
| 东风EQ5253GYYT3型运油车 | |
| 车 型 | EQ5253GYYT3型运油车 |
| 外型尺寸(mm) | 11000,11960×2500×3750 |
| 罐体总容量 | 20立方米 |
| 轴距(mm) | 5350+1300,5350+1350,5700+1300,5700+1350 |
| 总质量(kg) | 25000 |
| 额定载质量(kg) | 13500,13565 |
| 整备质量(kg) | 11305 |
| 发动机型号 | ISDe245 40,ISDe270 40,ISC8.3-245E40A,ISC8.3-270E40A,ISC8.3-292E40A, |
| 排量/功率 | 6700/180,6700/198,8300/180,8300/198,8300/215, |
| 底盘型号 | DFL1250A12 |
| 批次 | 239 |
| 东风EQ5253GJYT型加油车 | |
| 车 型 | EQ5253GJYT型加油车 |
| 外型尺寸(mm) | 9600×2495×3100 |
| 罐体有效容积 | 22.4立方米 |
| 轴距(mm) | 4350+1300,4350+1350 |
| 总质量(kg) | 25000 |
| 额定载质量(kg) | 14995 |
| 整备质量(kg) | 9810 |
| 发动机型号 | B220 30,B210 33,YC6J190-33,YC6J210-33, |
| 排量/功率 | 5900/162,5900/155,6494/140,494/155 |
| 底盘型号 | EQ1258KB3GJ |
| 批次 | 239 |
